产品介绍：

■ 1.执行标准 Executive standard （Q/321023KLA33）

 ■ 2.适用范围 Application range 本产品适用于交流额定电压35kv及以下的电力输配电线路，特别适用于地铁、隧道、电站、石油化工、高层建筑等对电缆阻燃性能有高要求的重要场合。 This product is suitable for power distribution circuit of AC rated voltage up to and including 35KV ,especially,applicable for important locations that requires cable with high anti-flaming performance such as underground railway,channel,power station.petrochemical,tall buidings,etc..

■ 3.产品结构图 Diagram of product structure 1

 1-导体 2-绝缘 3-隔火层 4-包带 2 5-内护 6-铠装 7-外护套 3 1-Condcutor 2-Insulation 3-Fire stop sealer 4-Bingding 4 5-Inner sheath 6-Armor 7-Outer sheath 5 6 7

 ■ 4.型号、名称 Type、Designation

产品型号名称见表1 Refer to table 1 for product model and name 型号Model 名称 Name

铜芯 Copper Conductor

铝芯 Aluminum conductor GZR-W GZR-VLV

聚氯乙烯绝缘聚氯乙烯护套隔火层阻燃电力电缆 PVC insulated and sheathed anti-flaming power cable with fire stop sealer anti-flaming power cable with fire stop sealer GZR-YJV GZR-YJLV

交联聚乙烯绝缘聚氯乙烯护套隔火层阻燃电力电缆 XLPE insulated PVC sheathed anti-flaming power cable with fire stop sealer GZR-VV22 GZR-VLV22

聚氯乙烯绝缘钢带铠装聚氯乙烯护套隔火层阻燃电力电缆 PVC insulated steel tape armored and sheathed anti-flaming power cable with fire stop sealer GZR-YJV22 GZR-YJLV22

交联聚乙烯绝缘钢带铠装聚氯乙烯护套隔火层阻燃电力电缆 XLPE insulated steel tape armored PVC sheathed anti-flaming power cable with fire stop sealer

产品规格见表2 Refer to table 2 for product specification

型号 Model 芯数 Core 额定电压KV Rated voltage KV 0.6/1 1.8/3 3.6/6、6/6 8.7/10 21/35、26/35

标称截面MM2 Nominal cross sectional mm2 GZR-VV GZR-VLV 1 2.5-300 - - - - GZR-YJV GZR-YJLV 2.5-300 10-300 25-300 25-300 50-300 GZR-VV GZR-VLV GZR-YJV GZR-YJLV GZR-VV22 GZR-YJLV GZR-YJV22 GZR-YLLV22 2 2.5-185 - - - - GZR-VV GZR-VLV 3 2.5-300 - - - - GZR-YJV GZR-YJLV 2.5-300 10-300 25-300 25-300 - GZR-VV22 GZR-VLV22 GZR-YJV22 GZR-YJLV22 4-300 - - - - GZR-VV GZR-VLV GZR-YJV GZR-YJLV GZR-VV22 GZR-VLV22 GZR-YJV22 GZR-YJLV22 4 4-185 - - - - GZR-VV GZR-VLV GZR-YJV GZR-YJLV 3+1 4-300 - - - - GZR-VV22 GZR-VLV22 GZR-YJV22 GZR-YJLV22 4-185 - - - - GZR-VV GZR-VLV GZR-YJV GZR-YJLV GZR-VV22 GZR-VLV22 GZR-YJV22 GZR-YJLV22 5 3+2 4+1 4-185 - - - -
